JLKY80-35 Hydraulic Choke Valve
The hydraulic Throttle Valve made in Jiangsu Shuangxin Petroleum Machinery Factory is used for adjusting flow rate of manifold and other equipment. The hydraulic throttle valve controls the rate of flow by raising or lowering the position of the valve core.
Main technical parameters
Rated pressure: 2000~15000psi
Working temperature: P U
Working medium: Petroleum, natural gas
Part list
|
Serial NO. |
Name |
Quantity |
Material |
Remark |
|
1 |
Valve body |
1 |
35CrMo |
|
|
2 |
Bushing |
1 |
FKM |
|
|
3 |
Valve seat bushing |
1 |
35CrMo |
|
|
4 |
O-ring |
1 |
Rubber |
|
|
5 |
Valve seat |
1 |
YG8 |
|
|
6 |
Fastening cap |
1 |
45 |
|
|
7 |
Valve core |
1 |
YG8 |
|
|
8 |
Lower fluid guide bushing |
1 |
2Cr13 |
|
|
9 |
Upper fluid guide bushing |
1 |
2Cr13 |
|
|
10 |
Valve stem |
1 |
2Cr13 |
|
|
11 |
O-ring |
1 |
Rubber |
|
|
12 |
O-ring |
2 |
Rubber |
|
|
13 |
Valve Bonnet |
1 |
35CrMo |
|
|
14 |
Oil cylinder |
1 |
35CrMo |
|
|
15 |
Oil cylinder joint |
2 |
35CrMo |
|
|
16 |
O-ring |
2 |
Rubber |
|
|
17 |
O-ring |
2 |
Rubber |
|
|
18 |
O-ring |
2 |
Rubber |
|
|
19 |
Piston |
1 |
45 |
|
|
20 |
Cylinder cover |
1 |
35CrMo |
|
|
21 |
Clip |
1 |
65Mn |
|
|
22 |
Screw |
4 |
35CrMo |
|
|
23 |
Washer |
1 |
35CrMo |
|
|
24 |
O-ring |
2 |
Rubber |
|
|
25 |
Valve bonnet nut |
8 |
40Cr |
|
|
26 |
Packing Gland |
1 |
40Cr |
|
|
27 |
Valve bonnet bolt |
8 |
35CrMo |
|
|
28 |
Packing ring |
2 |
2Cr13 |
|
|
29 |
Packing |
5 |
FKM |
|
|
